Vantrue 5-Level Adjustable Hardwire Kit (VP01) User Manual & Troubleshooting Guide
Vantrue VP01 acting up? Lost the booklet? No stress.
You’ve picked up the Vantrue 5-Level Adjustable Hardwire Kit (VP01) to get that sweet 24/7 parking mode running on your dash cam. Good choice. But if you’ve chucked the manual or the dip switches are doing your head in, don’t worry. We’ve got the digital manual, the breakdown of those voltage settings, and some expert tips to get you sorted.
💡 PRO TIP: Don't Kill Your SD Card
Hardwiring your camera for Parking Mode means it's running nearly 24/7. That kind of workload will fry a standard SD card in a few months. To avoid "Memory Error" loops, make sure you're using a dedicated High Endurance card.
Check out our recommended High Endurance VANTRUE SD Cards here.
Troubleshooting & Dip Switch Settings
The VP01 kit uses a little black box with "Dip Switches" to control two things: when to cut power to save your battery (Voltage Cut-off) and how long to keep the camera running (Timer). Here is the cheat sheet so you don't have to squint at the tiny sticker.
| Feature | Setting / Option | What it does |
|---|---|---|
| Voltage Cut-Off (12V Cars) | 11.6V / 11.9V / 12.2V / 12.5V | Stops power when your car battery hits this level. Recommendation: Set to 12.2V or 12.5V to ensure your car starts in winter. |
| Voltage Cut-Off (24V Trucks) | 23.6V / 23.9V / 24.2V / 24.5V | Same protection for trucks and heavy machinery. |
| Timer Settings | 1, 3, 6, 12, 24 Hours or "Always On" | Determines how long the camera records after you park. Tip: "Always On" will run until the battery voltage cut-off kicks in. |
| LED Indicator | Solid Red | Power is successfully reaching the hardwire kit. |
Frequently Asked Questions
1. Which voltage setting should I choose?
If you drive a daily commuter, 12.2V is usually the sweet spot. It gives you plenty of recording time without risking a flat battery. If your battery is older or you leave the car for days at a time, bump it up to 12.5V to be safe.
2. My dash cam turns off immediately when I turn off the car. Why?
This usually means the Yellow (ACC) wire isn't getting a signal, or the kit has cut power due to low voltage. Double-check that your Yellow wire is crimped to a fuse that turns on/off with the engine, and your Red wire is on a constant power fuse.
3. Can I use this with any dash cam?
This kit comes with a Type-C USB connector. It works perfectly with Vantrue models like the N4, N5, E1, E2, and X4S. If your camera uses Mini-USB or Micro-USB, this won't fit without an adapter (which we don't recommend).
4. Where does the Black wire go?
The Black wire is your Ground. It needs to be bolted to an unpainted metal part of the car's chassis. Do not attach it to plastic or a floating bolt on the dashboard; it needs a solid earth connection to work.
