VANTRUE VP05 User Manual & Troubleshooting Guide
VANTRUE VP05 acting up? Lost the booklet? No stress.
You've grabbed the VP05 Voltage Display Hardwire Kit to keep your Vantrue running 24/7, but now you're staring at a bunch of coloured wires wondering where to start. Don't sweat it. We've chucked together the official manual, a breakdown of those voltage settings, and some expert tips to get your rig sorted without blowing a fuse.
💡 Pro Tip: Don't Forget the Fuse Taps!
Wiring the VP05 directly into your fuse box can be a bit dodgy if you're just jamming wires in. For a clean, safe install that doesn't void your car's warranty, make sure you're using the correct Add-A-Circuit Fuse Taps for your vehicle type.
Troubleshooting & Voltage Settings
The VP05 is smarter than your average hardwire kit because it actually tells you what's going on with that little LED screen. Here's how to read it and set it up properly.
| Display / Component | Status / Setting | What It Means (The Fix) |
|---|---|---|
| Switch: Left Position | 12.4V (or 24.4V) | Safest Option. Cuts power early to ensure your car battery has plenty of juice to start the engine. Recommended for daily drivers. |
| Switch: Middle Position | 12.0V (or 24.0V) | Standard Balance. Good balance between recording time and battery safety. |
| Switch: Right Position | 11.6V (or 23.6V) | Max Recording. Allows the camera to run longer, but risks draining older batteries too low. Use with caution. |
| LED Display (Sequence) | Shows Set Voltage → Real Voltage | When you toggle the switch, it first shows your Cut-off Setting, then after 2 seconds, it switches to show your Car Battery's Actual Voltage. |
| No Power / Screen Off | Dark Screen | Check your ground wire (Black) is bolted to bare metal chassis. Check the fuse tap crimps are tight. |
| Parking Mode Issues | Cam turns off with car | You likely have the Red (Batt) and Yellow (ACC) wires swapped, or both connected to ACC fuses. Red must have power even when the key is out. |
Common FAQs
1. Which voltage setting should I choose?
Start with 12.0V or 12.4V. We reckon 11.6V is cutting it a bit fine for most Aussie cars, especially if your battery has seen a few winters. Only use 11.6V if you've got a brand new battery or a dedicated deep-cycle setup.
2. My dash cam turns off immediately when I turn off the car. What gives?
This usually means the kit isn't getting constant power. Double-check your Red Wire connection. It needs to be plugged into a fuse slot that stays "hot" (live) even when the ignition is completely off (like your hazard lights or horn).
3. Can I use this on a 24V truck?
No dramas. The VP05 automatically detects if it's a 12V or 24V system and adjusts the cutoff values accordingly (e.g., 23.6V instead of 11.6V).
4. Why is the screen showing a different number than what I set?
Remember the sequence: It shows your setting first, then switches to show the live voltage from your battery. If it's showing 12.6, that's just your car battery's current charge, not the cutoff setting.
Official User Manual
Need the full wiring diagram? Here's the official document straight from Vantrue.
