Vantrue Pilot 2 User Manual & Setup Guide
Getting ready for your Vantrue Pilot 2? Start here.
You have pre-ordered the Vantrue Pilot 2, the first dash cam we have stocked that reads heat as well as light. Whether you have gone for the full 4-channel system or the thermal-only build, this Vantrue Pilot 2 user manual guide walks you through the setup so you are ready the day it lands.
Which version do you have?
The full 4-channel system records four views at once: a 1440p front camera, a 1080p cabin camera, a 1440p rear camera and the dedicated thermal lens. It is a complete evidence system plus heat vision.
The thermal-only build is a single thermal camera feeding the big screen. It does not record colour footage of the road and will not capture number plates. It is a situational-awareness tool designed to run alongside a conventional dash cam, not replace one.
First-time setup
1. Get a memory card ready. A microSD card is not included in the box. The Pilot 2 supports high-endurance U3 cards up to a huge 1 TB (high-endurance means the card is built for the constant re-writing a dash cam does all day). Format the card in the camera before your first drive, not on your computer.
2. Mount the screen. The 6.25 inch touchscreen sits on your dash or windscreen. Pick a spot that does not block your view of the road, and keep it clear of airbag zones.
3. Mount the thermal camera outside. This is the step that makes the Pilot 2 different. The thermal module is IP67 weatherproof and mounts externally, usually behind the grille or on the front of the vehicle, with its cable routed into the cabin. Allow extra install time for this, or line up an independent professional through our installer directory. Fleet vehicles especially are worth doing properly.
4. Pair your phone. The screen supports Apple CarPlay and Android Auto, so your maps and music come along for the ride. Pair via the on-screen prompts, and connect the Vantrue app over Wi-Fi 6 for fast clip transfers.
5. Check for firmware updates. With a brand-new model, do this first. Early firmware updates fix the launch-week quirks, and the difference is often night and day.
💡 Pro Tip: What Thermal Can and Can't Do
The thermal camera detects the heat that people, animals and running engines give off, and Vantrue rate its AI as able to flag hazards up to roughly 100 metres away, well beyond your headlights. Fog, smoke, dust and darkness barely bother it.
What it cannot do is read a number plate. Plates do not glow with heat. For insurance-grade footage you want the optical cameras (on the 4-channel version) or a conventional dash cam running alongside the thermal-only build.
Setting up parking mode
Like every dash cam, the Pilot 2 needs constant power for parking mode, which means a compatible hardwire kit wired to the fuse box. Once connected, the system sleeps while parked and wakes to record when it detects an impact or motion. If you are new to how this works, our complete parking mode guide explains it in plain English.
Early troubleshooting basics
| Issue | What To Check |
|---|---|
| CarPlay / Android Auto Won't Pair | Toggle Bluetooth and Wi-Fi off and on, forget the device on both ends, and pair fresh. Keep your phone's operating system updated. |
| Thermal Image Looks Hazy | Road grime on the lens dulls heat detection. Clean the thermal lens gently with a microfibre cloth, never a dry scratchy wipe. |
| "Card Error" Message | Format the card in the camera menu. If it persists, use a high-endurance U3 card from a reputable brand. |
| False Hazard Alerts | Expect a short learning curve in busy areas. Adjust alert sensitivity in the settings once you have a feel for your usual routes. |
Frequently Asked Questions
1. Does the thermal-only version replace my dash cam?
No. It records a single thermal channel with no colour footage and no plate capture. Run it alongside a conventional dash cam (or the Full 4CH system) for evidence coverage.
2. Who is the Pilot 2 actually for?
Firefighters and emergency services working in smoke, farmers and graziers on unlit tracks, miners on dusty haul roads, and any night-shift or outback driver who wants to spot wildlife well before the headlights do.
3. Is a memory card included?
No, grab a high-endurance U3 card up to 1 TB. We suggest 256 GB or larger for the 4-channel system since four views fill a card quicker.
Official User Manual
(Scroll to read the full document)
Last reviewed: 19 August 2026. This is a new model and the settings, menu names, detection ranges and default values described here follow Vantrue's own published material rather than our own testing. Firmware updates change them, so if something on your camera does not match, check the current manual linked on this page. If a specification, a feature or a price on this page is wrong or has gone out of date, tell us and we will correct it.
