VIOFO BP100 Battery Pack User Manual & Troubleshooting Guide
VIOFO BP100 acting up? Lost the booklet? No stress.
You’ve invested in the VIOFO BP100 to keep your dash cam running while parked, but now you need to decipher the blinking lights or check the wiring specs. We’ve got the digital copy of the manual right here, along with a quick cheat sheet to get you sorted without scrolling through pages of text.
💡 Pro Tip: Charging Speed
Did you know the BP100 charges nearly twice as fast when hardwired compared to using the cigarette lighter adapter? If you want a full charge in ~45 minutes, ditch the 12V socket and hardwire it directly to the fuse box.
1. LED Status Indicators (The Cheat Sheet)
Trying to figure out what the light show means? Here is the breakdown so you know if you're charging, connected, or running low.
| LED Colour | Behavior | Meaning |
|---|---|---|
| Blue | Flashes | Bluetooth standby (Not connected) |
| Blue | Constant | Bluetooth connected to App |
| Red | Flashes | Battery is Charging |
| Green | Constant | Battery Level: 80% - 100% |
| Yellow | Constant | Battery Level: 21% - 79% |
| Red | Constant | Battery Level: 5% - 20% |
| Red | Fast Flash | Battery Empty (Below 5%) |
2. Technical Specifications
Just checking the voltage limits? Here are the numbers that matter.
| Input Power | Cigarette lighter: 11.8V~28V (6A Max) Hardwire: 11.8V~28V (11A Max) |
| Output Power | Dash cam port: 11.8V ~ 14.2V (3A) Type-C port: 5V (3A) |
| Capacity | 12.8V / 7650mAh / 98Wh |
| Run Time | Approx. 32 hours (based on a standard 3W dual-channel load) |
3. Frequently Asked Questions
Can I hook up more than one BP100?
Yeah, you can. The BP100 supports expansion. You can daisy-chain a secondary battery pack to double your parking mode duration.
My Viofo App won't find the battery via Bluetooth. Why?
This is usually a permissions issue on your phone. Make sure you’ve allowed the Viofo App access to "Location" and "Nearby Devices" in your phone settings. Without that, it can't scan for the battery.
What do the L / H / OFF switches do?
This controls the input current. Set it to L (Low) if you are using the cigarette lighter adapter. Set it to H (High) if you have hardwired the unit to the fuse box for faster charging. OFF cuts the power completely.
Official User Manual
(Scroll to read the full document)
Last reviewed: 19 August 2026. The capacities, voltages and run time quoted here are VIOFO's own published figures for this model rather than our own measurements, and firmware or hardware revisions can change them, so check the current manual linked on this page if something does not match. If a specification, a feature or a price on this page is wrong or has gone out of date, tell us and we will correct it.
